H=4.0 2mm Pitch Female Header MiNi Jumper Body Close Type Phosphor Bronze

Product Categories
WCON ELECTRONICS ( GUANGDONG) CO., LTD
Contact Now

H=4.0 2mm Pitch Female Header MiNi Jumper Body Close Type Phosphor Bronze

  • 1
  • 2

Brand Name : WCON

Model Number : 3711-4001XCXXB01

Certification : SGS/ROHS

Place of Origin : China

MOQ : 1000pcs

Price : negotiation

Payment Terms : T/T

Supply Ability : 800000pcs

Delivery Time : 15~25Day

Packaging Details : bag packing

Product height : 4.0mm

Current Rating : 1.0AMP

Contactt Resistance : 30mΩ Max

Withstand Voltage : 100V AC/DC

Contact Now

H=4.0 2.00mm MiNi Jumper WCON Connector Body Close Type oversized jumper womens

H=4.0 2mm Pitch Female Header MiNi Jumper Body Close Type Phosphor BronzeDrawing:3711-4001CXXX01.pdf

Current Rating 1.0AMP
Contactt Resistance 30mΩ Max
Withstand Voltage 100V AC/DC
Insulation Resistance 500mΩ Min
Operation Temperature ﹣40℃ to +105℃
Contact Material Phosphor Bronze
Contact Plating Au Over Ni
Insulator Material PBT Black+30%GF

H=4.0 2mm Pitch Female Header MiNi Jumper Body Close Type Phosphor Bronze
